20 Ton Capacity Tube Ice Plant

Name: 20 Ton Capacity Tube Ice Plant
Brand: Mukuls Project
Price: 6800000 INR
Availability: InStock

Price 6800000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

20 Ton Capacity Tube Ice Plant Specification

Product Type
Tube Ice Plant

General Use
Industrial Ice Production

Material
Stainless Steel & Mild Steel

Type
Fully Automatic

Capacity
20 Ton per 24 Hours

Weight (kg)
16500

Computerized
Yes

Automatic
Yes

Control System
PLC Based Automatic Control Panel

Cooling System
Ammonia/ Freon Based Vapour Compression

Tank Capacity
5000 Liters (approx.)

Hopper Capacity
1000 Kg

Loading Capacity
20 Ton/day

Condenser
Shell and Tube/ Evaporative

Freezing Cylinder
Vertical Stainless Steel Cylindrical Shells

Voltage
380-440 V, 3 Phase, 50 Hz

Dimension (L*W*H)
6500 mm x 2200 mm x 3200 mm

Feature
High Efficiency, Heavy Duty, Energy Saving, Corrosion Resistant

Color
Silver & Blue

Cycle Time
20-25 Minutes per Batch

Compressor Power
110 kW

Service Required
Minimal, Routine Checkups

Refrigerant
Ammonia R717 or Freon R404A

Water Source
Fresh or Brackish Water

Tube Ice Length
30-50 mm (customizable)

Ice Tube Size
22/28/34/40 mm (diameter, optional)

Ambient Working Temperature
Up to 50°C

Ice Discharge Method
Automatic bottom discharge with screw conveyor

Noise Level
< 75 dB

Installation Requirement
Concrete Platform & Foundation

Power Consumption
Approx. 90-110 kW/Ton

20 Ton Capacity Tube Ice Plant Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
1 Piece Per Day

Delivery Time
1 Days

Main Domestic Market
All India

About 20 Ton Capacity Tube Ice Plant

Production Output	20 ton/24 Hrs
Material	Mild Steel
Automation Grade	Automatic
Brand	Neer Projects
Refrigerant	Ammonia
Compressor	Screw Compressor
Condenser Temp	40 Deg C
Condenser Pump	4 HP
Ambient Temp	35 Deg C
Country of Origin	Made in India
Availability	In Stock

We are engaged in offering 20 Ton Capacity Tube Ice Plant to our clients. Our range of all products is widely appreciated by our clients.
Specification:
Available In Different Sizes And Varients

Advanced Automatic Ice Production

This plant incorporates vertical freezing cylinders with a fully automatic operation, ensuring consistent ice tube production with minimal manual intervention. Featuring a PLC-based control panel and computerized monitoring, you can expect precise and efficient performance around the clock, supporting large-scale industrial needs.

Flexible Ice Specifications and Discharge

Ice tube size (diameter) is selectable, ranging from 22 to 40 mm, with lengths customizable between 30 and 50 mm, tailored to various applications. The automatic bottom discharge, enhanced by a screw conveyor, ensures seamless, labor-saving output directly from the plant to storage or transportation units.

Built to Withstand Harsh Conditions

Designed using corrosion-resistant materials, this plant endures demanding industrial settings and temperatures up to 50C. The heavy-duty shell and tube or evaporative condenser options and high-capacity water and hopper tanks ensure uninterrupted, high-efficiency operation.

FAQ's of 20 Ton Capacity Tube Ice Plant:

Q: How does the automatic ice discharge system work in the tube ice plant?

A: The plant's automatic bottom discharge uses a screw conveyor mechanism, ensuring continuous and seamless removal of ice from the freezing cylinders directly to the hopper or transport containers, reducing manual labor and increasing operational safety.

Q: What types of water sources can be used in this tube ice plant?

A: This plant is suitable for both fresh and brackish water sources, allowing flexibility for various industrial and environmental requirements without compromising ice quality or machine efficiency.

Q: When should routine service or checkups be performed on the ice plant?

A: Routine checkups are minimal but recommended periodically, depending on operational intensity. Monitoring key components, refrigerant levels, and cleaning the system ensures continued high efficiency and prolongs equipment life.

Q: Where should the tube ice plant be installed?

A: The plant requires installation on a concrete platform and foundation, providing the stability necessary for its 16,500 kg structure and ensuring safe, vibration-free operation in industrial environments.

Q: What are the main benefits of using this 20-ton tube ice plant for industrial applications?

A: Key benefits include high daily ice output, customizable ice sizes, energy-saving features, minimal maintenance, and robust operation in ambient temperatures up to 50C. The plant is engineered from corrosion-resistant materials for durability and long service life.

Q: How is the tube ice size customized in this plant?

A: Ice tube diameter can be selected from available options (22/28/34/40 mm), and length is adjustable between 30-50 mm. Adjustments are made via the control panel to match customer or process requirements.

Q: What process does the plant follow to produce tube ice?

A: The plant uses a vapor compression cycle with Ammonia or Freon refrigerant. Water from the tank circulates in vertical stainless steel cylindrical shells, freezing to form ice tubes in cycles of 20-25 minutes. The ice is then automatically discharged, cut to length, and conveyed for storage or use.
